Keysight Agilent N5235A PNA-L Microwave Network Analyzer 50 GHz with 122 dB Dynamic Range and 2 or 4 Ports

Brand Name : Keysight/Agilent

Model Number : N5235A

Certification : ISO17025 calibrated

Place of Origin : Malaysia

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T

Supply Ability : in stock

Product Name : PNA-L Microwave Network Analyzer

No. of ports : 2 ports or 4 ports

Condition : Pre-Owned

Frequency : 10 MHz-50 GHz

Functions : Tested, in Full Working Conditions

Dynamic Range : 122 dB

Contact Now

Keysight Agilent N5235A PNA-L Microwave Network Analyzer 50 GHz
Product Overview

The Keysight N5235A PNA-L series Network Analyzer provides design and manufacturing electrical engineers with a high-performance mid-range Vector Network Analyzer solution. This instrument delivers extremely accurate S-parameters at a competitive price point, with upgradeable capabilities that extend its useful lifespan.

The N5235A PNA-L VNA replaces and maintains full compatibility with the existing N5230C model, ensuring no changes to your existing setup or test codes.

Key Benefits
  • Optimal balance of speed and performance for manufacturing applications
  • Higher yields and tighter guard bands with superior mid-range VNA performance
  • Enhanced throughput and repeatability for competitive product development
  • Fast, accurate S-parameter measurements with future-proof capabilities
  • Exceptional price-to-performance ratio for microwave manufacturing
Technical Specifications
Maximum Frequency 50 GHz
Dynamic Range 122 dB
Output Power 6 dBm
Trace Noise 0.003 dBrms
Number of Built-In Ports 2 or 4 ports
Harmonics -33 dBc
Noise Floor -116 dBm
Best Speed at 201 Point, 1 Sweep 6 ms
Network Analyzer Series PNA-L Economy
Instrument Type Vector Network Analyzer
Components Cables, Filters
Benchtop Yes
Applications
  • S-parameters
  • Gain compression
  • Conversion gain/loss
  • Material measurements
  • Signal integrity
Available Options
Option Code Description
007 Automatic Fixture Removal
010 Time domain
015 Dynamic Uncertainty for S-Parameter Measurements
080 Frequency offset measurements
082 Scalar calibrated converter measurements
083 Vector- and scalar-calibrated converter measurements
084 Embedded LO measurements
090 Spectrum Analyzer
1A7 Calibration + Uncertainties + Guardbanding
1CM Rack mount kit for installation without handles
1CP Rack mount kit for installation with handles
200 2 ports, base hardware configuration
216 2 ports, configurable test set, source attenuators
301 Application for use with standard CalPods
302 Application for use with temperature-characterized CalPods
551 N-port calibrated measurements
897 Built-in performance test software for inclusive calibration, perpetual license
898 Built-in performance test software for standards compliant calibration, perpetual license
Support Information

The range of repair and standard technical support for this model narrowed on June 1, 2024. Full supportability can be regained through Keysight's hardware and firmware upgrade program to a B-model at a fraction of the price of a new unit. This program ends on December 31, 2025.

Frequently Asked Questions
Can you ship orders to Canada or Australia?
Yes, we ship orders worldwide.
What delivery methods do you use and what is the delivery time?
We ship by EMS, DHL, FedEx, UPS, TNT with tracking numbers. Standard delivery time is 4-7 business days.
What is your payment term?
100% T/T payment before shipment.
How can I ask any other questions?
You can contact us online or leave us messages below.
